ISCOM6820-GP (A) Installation Guide
6 Checking hardware installation
Raisecom Proprietary and Confidential
Copyright © Raisecom Technology Co., Ltd.
34
Table 6-2 Checklist of cabinet or workbench
Item
Requirement
Cabinet

Structure attachments are installed correctly and reliably, switches of
doors and locks work normally.

All other connection bolts are installed correctly and reliably, the flat
washers and spring washers are installed in a correct order.

The installation location meets the engineering design manual.

The installation is fixed and reliable and consistent with the anti-seismic
requirements described in the engineering design manual.

The ground cable is correctly connected.

The ESD wrist strap is connected to the ESD jack on the cabinet.
Workbench

The installation location meets the engineering design manual.

The installation is fixed and reliable and consistent with the anti-seismic
requirements described in the engineering design manual.

The ground cable is correctly connected.

The ESD wrist strap is connected to the ESD jack on the cabinet.
6.3 Checking chassis and cards
Check the chassis and card after installation according to Table 6-3.
Table 6-3 Checklist of chassis and card
Item
Requirement
Chassis

Placed firmly and there is enough space for heat dissipation and
operation around the device. The ground cable is connected
correctly.

Fill unoccupied slots with blank panels for dust prevention and
electromagnetic shielding.
Components

The installation slots of all components are correct.

Install all components firmly without slackening.
6.4 Checking cables
Check cables after installation according to Table 6-4.
