GB-F-NL-12
GB
SPECIFICATIONS
ENGINE SPECIFICATION
TYPE: Kubota 15.5KW (20.9HP) @ 3600 RPM, 3
cylinder (in line) vertical Diesel engine, 4
stroke, water cooled, 719cc (43.88 cu.in)
with 12V electric start.
Model: D722-E
Maximum Speed: 3400 RPM (No load)
Idle Speed: 1600
RPM (No load)
Oil Sump Capacity: 3.2 litres (5.6 Imp.pints) (6.7 US pints)
Firing Order: 1, 2, 3.
Fuel: No. 2-D Diesel fuel (ASTM D975)
MACHINE SPECIFICATION
Frame construction: Main chassis of formed steel bolted
construction, front axle and mounting
points for units bolted to chassis.
Transmission: Direct coupled variable displacement
pump, front wheel motors 190 cc and rear
wheel motor 190cc with selectable three
wheel drive.
Cutting unit drive: Fixed displacement direct coupled pump,
fixed displacement unit drive motors direct
coupled to unit operated by forward,
neutral, reverse valve
Speeds:
Cutting: 8 km/h (5 mph)
Transport: 13 km/h (8 mph)
Reverse: 6.5 km/h (4 mph)
Steering: Hydrostatic power steering on rear wheel.
Tyres:
Front - 20 x 10.0 - 8 4ply turf tread
Rear - 20 x 10.0 - 8 4ply turf tread
Pressures: All tyres 1.0 kg/cm
2
(14 p.s.i.)
Ground pressure: 0.84 kg/cm
2
(12 p.s.i.)
Brakes: Hydrostatic braking with mechanical
type disc parking brakes, on front wheels
Cooling System 4.26 litres (7.5 Imp.pints) (9 US pints)
Capacity:
Fuel Tank
Capacity: 27 litres (6 Imp. gal.) (7.2 US gal.)
Hydraulic Tank
Capacity: 27 litres (6 Imp. gal.) (7.2 US gal.)
Battery: 12 volt 43 amp/hr type 085
DIMENSIONS - SERIES UL
Width of cut: 1.80 meters (71in)
Overall width: 2.05 meters (81in)
Overall width: (transport) 1.65 meters (65 in)
Overall height: 1.22 meters (48 in)
Overall length with catchers: 2.54 meters (100in)
Overall length without catchers:2.34 meters (92in)
Wheelbase: 1.31 meters (51.6in)
Uncut turning circle: 1.00 meters (39.4 in)
Overall weight of machine: 890kg (1962lb)
