DIMENSIONS - SERIES US
Width of cut: 1.80 meters (71in)
Overall width: 2.05 meters (81in)
Overall width: (transport) 1.65 meters (65 in)
Overall height: 1.22 meters (48 in)
Overall length with catchers: 2.54 meters (100in)
Overall length without catchers:2.34 meters (92in)
Wheelbase: 1.31 meters (51.6in)
Uncut turning circle: 1.00 meters (39.4 in)
Overall weight of machine: 894kg (1971lb)
VIBRATION LEVEL
The machine was tested for whole body and hand/arm
vibration levels. The operator was seated in the
normal operating postion with both hands on the
steering mechanism. The engine was running and the
cutting device was rotating with the machine
stationary.
Series UL
Hand / Arm acceleration level :1.25 m/s
2
Whole body acceleration level
X axis :0.22 m/s
2
Y axis :0.18 m/s
2
Z axis :0.51 m/s
2
Series US
Hand / Arm acceleration level : 1.03 m/s
2
Whole body acceleration level
X axis : 0.18 m/s
2
Y axis : 0.16 m/s
2
Z axis : 0.47 m/s
2
NOISE EMISSION - SERIES UL
Conforms to the specification of Directive EEC 79/113, 84/558,
87/252, 88/180, 88/181.
Sound Power Level: 101dB(A) LWA (Bystander)
Sound Pressure Level: 86.9dB(A) LpA (Operator Ear Level)
NOISE EMISSION - SERIES US
Conforms to the specification of Directive EEC 79/113, 84/558,
87/252, 88/180, 88/181.
Sound Power Level: 103dB(A) LWA (Bystander)
Sound Pressure Level: 88.1dB(A) LpA (Operator Ear Level)
RECOMMENDED LUBRICANTS
Engine oil: Should be to MIL-L-2104C or to A.P.I.Classification
CC/CD/CE grades and as given in the table below:
Temperature Oil Viscosity
ABOVE 25°C (77°F) SAE 30 or SAE10W-30
SAE10W-40
0°C to 25°C (32°F to 77°F) SAE 20 or SAE10W-30
SAE10W-40
BELOW 0°C (32°F) SAE 10W or SAE10W-30
SAE10W-40
Hydraulic Oil: Shell Harvela or equivalent.
Grease: Shell Darina R2 or equivalent.
