ELECTRICAL CIRCUIT
ENGINE AND SAFETY
Fig.55
1. Battery
2. Starter motor and solenoid
3. Alternator
4. Hourmeter
5. Engine over temperature warning lamp
6. Heater warning lamp
7. Engine oil, pressure warning lamp
8. battery charge warning lamp
9. Seat switch delay
10. Relay 1 (safety circuit - seat switch)
11. Relay 2 (safety circuit - mow, fwd/rev switch)
12. heater lamp timer
13. Engine heaters
14. Engine stop solenoid
15. Seat microswitch
16. Traction forward / reverse microswitch
17. Mow forward / reverse switch
18. Fuel pump
19. Oil pressure switch
20. Engine over temperature switch
21. Stop solenoid timer
22. Key switch
23. Mow forward solenoid
24. mow reverse solenoid
25. Mow lamp
26. RH L/A switch
27. Centre L/A switch
28. Mow foot switch
29. Relay 3 (safety circuit - mow circuit)
30. Mow switch
31. Backlap lamp
32. 3WD Switch
33. 3WD lamp
34. 3WD solenoid
35. Over temperature test switch
36. Over temperature relay
37. Over temperature horn
38. Earth
Key switch positions
39. Off
40. Preheat
41. Crank
42. Run
43. Working light connection
GB
F1 Fuse 10amp
F2 Fuse 10amp
F3 Fuse 15amp
F4 Fuse 30amp
F6 Fuse 10amp
F10 Fuse 40amp
D1 Diode
D2 Diode
D3 Diode
D4 Diode
D13 Diode
CABLE COLOUR CODE
R Red
G Green
O Orange
S Grey
B Black
W White
K Pink
P Violet
Y Yellow
U Blue
N Brown
LG Light Green
