We built our units by level. That means the
pan is in accordance with the frame. Once you have
levelled the frame, the pan should be levelled also.
The levelling is done exclusively by adjusting the
foots of the unit. Proceed as follows:
Step 1
Units are delivered with the foots fully screwed.
Before starting to level the unit unscrew each foot
of two turns. Pict. 1
Step 2
Put your level on the right or left pan as you like.
Start levelling the unit from the left to the right. To
do so adjust the front legs of the device.
Pict. 2
Check now the setting on the opposite pan.
Step 3
Put your level on the right or left pan as you like.
Now you can level the unit from the front to the rear.
To do so adjust the rear feet of the unit.
Pict. 3
Check on the opposite pan.
Levelling: 112 units
- 13 -
