We highly recommend you to transport the
unit as far as you can on a pallet jack.
Center of gravity Pict. 1
Required passage width with pallet:
Models 112 / 211 / 311 1010 mm / 40"
Devices maximum size: Pict. 2
X (mm) Y (mm) H* (mm)
112+ 780
30 3/4"
1220
48 1/8"
1100
43 3/8"
211+
920
36 1/4"
1164
45 7/8"
311+ 1542
60 3/4"
* H = Height with standard foots
Height of the standard foot = 150 mm (6")
Dimensions and weight of units with packaging
X (mm) Y (mm) Z (mm) P (kg)
112
1325
52 1/4"
1300
51 1/4"
1000
39 1/2"
202
112+ 212
211 230
211+ 257
311
1700
67"
299
311+
335
Pict. 3
Handling: Size for carrying
- 8 -
