Requirement
You need to ensure, depending on the
national and local regulations, that each of our
devices are separately connected through a
30mA RCD circuit breaker. This device must
be located in the electrical distribution box.
Regulation
• Follow the installation instructions
and the information on the name-
plate when connecting the unit
(See plate description on next page).
• Equipment must be connected to an electrical
supply line with standards in your country.
• Observe your local electricity supplier regula-
tions.
• On-site installation: provide accessible all-pole
disconnection device with a minimum of a 3
mm contact gap.
• Applicable standards: EN 60335, IEC 60335
Power supply cable:
• Electrical connection data see page 17
• For appliance connections, precise dimensions
and connection points, see pages 15 - 18 or
data sheets page 28 - 30.
• Units can be connected directly or through a
suitable connector.
• Before connecting or disconnecting the mains
be sure the unit is switched off.
• Use at least a cable quality like HO7RN-F
if flexible, V1000R02V if rigid. Take
care to tighten enough the cable gland.
(Stress relief)
• The cross-section of the power cables must be
based on the current consumption and on local
regulations.
Electric wiring diagrams
• The wiring diagram can be found inside
a plastic bag in the technical compart-
ment, after removing the side panel. See
chapter: installation, accessing the units.
Please put it again there after using it.
Power supply: Common information
- 14 -
