Floor fixing plate
It is possible to fix units to the floor using the
optional set"Set for floor fixing" 60.72.905
Pict 1
Attention!
When installing 211 - 311 models with pressure on
the standard foots, we highly recommend to fix the
foots to the floor. This in order to ensure the levelling
of the unit as the alignment between lid and pan
remains unaltered.
Option casters
Attention!
It is forbidden to mount casters on 211+ - 311+
models with pressure option and build before
Mai 2012.
Units ordered with option casters will be delivered
with standard foots. The mounting of the casters
must be done on site. Pay attention that the casters
with brakes are installed at the front of the unit.
Pict. 2
Mounting instructions is supplied with casters.
Casters Kit reference (for all models) 60.71.267
The height of the unit on casters is 150 mm (5 7/8")
Option adjustable stainless steel foots
All models of VarioCooking Center
®
can be deliv-
ered with stainless steel foots. These feet make it
possible to fix the apparatuses on the ground via an
integrated washer.
Pict. 3
h min 105 mm (4 1/8")
h max 170 mm (6 6/8")
Article number (Single) 12.00.850
Installation Options
- 24 -
