15 Move the same weight to position D
16 Press the "Zero" button, to accept the weight (load cell
output) value.
17 A new value will show on the display (example 45582).
Then "Done" will show on the display.
FK0368.eps
15
16
17
Position D
3.2-4 Corner Calibration (continued)
