38 6823346-R3
12 Move the same weight to position C.
NOTE: To locate Position C on a Logistics iFork, refer to
the illustration shown under "Logistics iForks – Locate
hidden load cells", page 32.
13 Press the "Zero" button, to accept the weight (load cell
output) value.
14 A new value will show on the display (example 45340).
Then "Corn D" will show on the display.
FK0367.eps
12
13
14
Position C
3.2-4 Corner Calibration (continued)
