Manual No. 016-0171-496 Rev. C 15
Standard AccuFlow™ Installation
Mounting the AccuFlow™ System
Use the provided u-bolts and hardware (P/N 107-0159-447) to mount the AccuFlow system directly to the
frame of the tool bar or implement. The intake port of the AccuFlow super cooler should be pointing toward the
rear of implement and nurse tank.
FIGURE 4. AccuFlow™ Mounting Example
