Raven AccuFlow - Accuflow HP Kit Contents

Chapter 2
8 AccuFlow™ and AccuFlow HP™ Installation & Operation Manual
AccuFlow HP™ Kit Contents
Please review the following tables for components, parts, and fittings which should have been supplied with the
Raven AccuFlow HP system. It may be necessary to order some components of the AccuFlow system
separately. Before beginning assembly and installation, verify that all required components have been
purchased.
Note: To provide the most responsive control of anhydrous ammonia applications when using a multi-
section tool bar, a check valve assembly (P/N 063-0173-030, ordered separately) should be
installed if the section on/off valves are mounted next to the distributor manifolds. Refer to the
diagrams provided in Chapter 3, Standard AccuFlow™ Installation, for location. Contact a local
Raven dealer for more information.
See Chapter 9, System Diagrams, for detailed diagrams and system connections.
Two Valve, Dual Cooler AccuFlow HP™ Kit (P/N 117-0171-392)
Fast Valve, Dual Cooler AccuFlow HP™ Kit (P/N 117-0171-393)
AccuFlow HP™ Pump Control Kit (P/N 117-0171-334)
Qty. Components P/N
1 • Kit, AccuFlow HP Hydraulic 117-0141-002
1
• Assembly, Two Valve - Dual
Cooler AccuFlow HP
063-0173-292
2 • Hose, Anhydrous Vapor 214-0001-036
1
• Manual, AccuFlow Operation
Manual
016-0171-496
2 • Rope, 1/4” Poly Braided 321-0000-359
4 • U-bolt, 2-1/16” x 4” x 3/8” THD. 321-0000-363
8 • Nut, 3/8” Flange Lock 312-1001-164
1 • RectorSeal 222-1001-088
Qty. Components P/N
1 • Kit, AccuFlow HP Hydraulic 117-0141-002
1
• Assembly, Fast Valve - Dual
Cooler AccuFlow HP
063-0173-293
2 • Hose, Anhydrous Vapor 214-0001-036
1
• Manual, AccuFlow Operation
Manual
016-0171-496
2 • Rope, 1/4” Poly Braided 321-0000-359
4 • U-bolt, 2-1/16” x 4” x 3/8” THD. 321-0000-363
8 • Nut, 3/8” Flange Lock 312-1001-164
1 • RectorSeal 222-1001-088
Qty. Components P/N
1 • Node, Single Product Control 063-0172-373
1 • Cable, AccuFlow HP Node 115-0171-909
