C hapter 4 Standard AccuFlow™
Calibration and
Operation
This chapter contains information on calculating or adjusting calibration values for the AccuFlow™ system.
These values must be programmed on the console providing product control. Refer to the control console
Installation and Operation manual for detailed programming instructions.
Note: Before the AccuFlow system and connected console may be used to control anhydrous ammonia
application, the following calibration values must be programmed on the Raven product control
console:
• Boom Cal
• Speed Cal
• Meter Cal
• Valve Cal
• Rate Cal
Programming NH
3
Rate Control
Adjusting the Boom Cal
The boom cal for the AccuFlow system can be calculated with the following formula:
Number of Applicator Knives x Spacing in inches [centimeters] = Implement Width
(EQ 1)
For Example:
If the implement has 16 knives spaced 30 inches apart, the calculated implement width is equal to 480 inches.
Enter 480 as the boom cal on the control console.
Adjusting the Speed Cal
Calculate the speed cal according to the console’s Installation and Operation manual. No adjustments to the
speed cal are required for the AccuFlow system.
