Chapter 3
22 AccuFlow™ and AccuFlow HP™ Installation & Operation Manual
Dual Cooler Installation
The following diagrams are provided to assist with mounting and connecting an AccuFlow™ dual cooler
system.
FIGURE 11. Dual Cooler AccuFlow System (D/N 016-0171-508)
DANGER
Anhydrous ammonia in vapor form can cause
serious injury or death. Pipe joints must be
properly sealed with RectorSeal™, or an
equivalent thread sealant, to prevent leaks.
