38 AccuFlow™ and AccuFlow HP™ Installation & Operation Manual
FIGURE 6. AccuFlow HP Assembly
FIGURE 7. Vapor Tube Distribution Using 3/4” Vapor Tubes
NH
3
Boost Pump
Flow Meter
Check Valve
