Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000M-CE
Figure 4 Laser top lifting ring and bottom level adjustment caster.
CAUTION: All the cables can only be connected when power supply is off. Hot plug
may damage the device.
CAUTION:
(1) The placement of the laser output cable should be as natural as possible, and the
output cable should not be twisted;
(2) If the coil diameter of the output optical cable is too small, it will damage the laser.
CAUTION:
(1)In the process of installation and disassembly, please handle the laser output head
gently, and avoid vibration;
(2) Before assembling the laser output head, ensure that the optical lens and cutting head
cavity are clean and free of pollution.
