User Guide of RFL-C20000M-CE
Figure 50The programming interface in programming editing mode
8.13.1 View the number of wave bars inside the current laser
Operating interfaces of view the number of wave bar stored inside the current laser is as Figure 51.
The software automatically lists the number of wavelength bars that have been saved by click on the
„Refresher List‟ button. Green indicates the bar already has a program and white indicates that the bar is
empty.
Figure 51 operating interfaces of wave bar stored inside the current laser
