23
Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C20000M-CE
C3~C6
Selecttheoptic
algate
channel
Input
signal
C3 is the lowest bit, C6 is the highest bit:
0000-close all optical gate channels;
0001-open channel 1;
0010-open channel 2;
0011-open channel 3.
(For lasers withoptical gate channels only, these
pins are spare in other lasers)
C7
Enable QCW
mode
Input
signal
Enable QCW mode(For lasers with QCW modes
only)
C8~C16
Not connect
B1
The laser is
ready
Output
signal
The laser is ready to emit laser light when B1 is
high.
B2
Laser output
Output
signal
The laser is emitting light when B2 is high.
B3
The laser
operates in
internal mode
Output
signal
The laser works in the internal control mode
when B3 is high. In this mode, the laser can be
controlled by communication.
B4
Laser
anomalies
Output
signal
The laser is abnormal when B4 is high.
B5
Laser red
light
indication
Output
signal
The laser is emitting guide light when B5 is high.
B6
AD mode
Output
signal
The laser works in the AD mode when B6 is
high.
B7
Feedback
signal ofA1
Output
signal
The laser has received the A1 signal when B7 is
high.
B8
Main power
supply of
laser
Output
signal
The main power of laser is on when B8 is high.
B9
Program
running
Output
signal
Laser program is running when B9 is high.
B10
Program
ending
Output
signal
Laser program is ended when B10 is high. B10
clears when the A2 is invalid.
B11
Abnormal
Wave Mode
Termination
Output
signal
Laser program is ended abnormally when B11 is
high. B11 can be cleared when the A4 is high.
B12
Synchronous
output
Output
signal
Sync signal output in programming mode.
