User Guide of RFL-C20000M-CE
Table 17command meaning in laser working status
Code (1 Byte)
Parameter1(2 bytes）
Parameter 2（4 bytes）
Note
1
Stop
none
none
The program end
command. the last
command must be this
command.
2
SPT
0～65000（ms）
0～65000(W)
Change power to 2 in
time 1
3
SPR
0～65000（W/ms）
0～65000(W)
Change power to 2 in
power change ratio 1
4
WAIT
1
Wait for sync
signal low level
Null
2
Wait for sync
signal high level
Null
3
Wait for sync
signal rising
Null
4
Wait for sync
signal droping
Null
5
Wait
0～65000ms(int)
5
GOTO
0～99
line
-1
Switch at low sync
signal
Jump to different line
when comply
0～99
line
-2
Switch at high
sync signal
Jump to different line
when comply
0～99
line
0 ~
1000000
timesof jump to
subject line
Times of loop jump to
subject line
6
OUT
1
SO
1
sync signal low
level output
2
sync signal high
level output
7
EXT
Power
1
0～10V
2
