Raymarine autopilot control unit User Manual

Appendix: Using the ST7001+ With Non-150/400 Autopilots 107
Appendix
or
or
1 sec
1 sec
or
or
1 sec
or
or
2 seconds
2 seconds
(saves changes)
Calibration Mode Overview
100/300 Autopilot Systems
Calibration Mode
Within DISPLAY CAL, COMPASS CAL and DEALER CAL:
-- press disp or to move forwards through items
-- use -1, +1, -10, +10 to adjust settings
-- press standby for 2 seconds to save changes
D5492-1
standby
auto
-1 and +1
standby
auto
standby
auto
Vessel type
Calibration lock
Rudder gain
Counter rudder
Align rudder
Rudder limit
Turn rate limit
Cruise speed
Off course alarm angle
AutoTrim
Power steer on/off
Drive type
Rudder damping
Magnetic variation
AutoAdapt
Latitude
WindTrim (Displacement only)
AutoTack (Displacement only)
AutoRelease (Sterndrive only)
Response level
Swing compass
Compass deviation
Align heading
Display bar selection
Heading type
Pop-up pilot time-out
Data pages 1 to 15
