–T
otalFuelCapacity—Specifythetotalfuelcapacityofyourfueltanks.
–FuelCalculations—SwitchfuelcalculationbetweenFuelUsed(Trip)andFuelflowrate.
–Detectfuelmessages—Scansthesystemforavailable,supportedfuelrelatedmessages.
8.3Settingupthefuelmanager
TheFuelmanagerrequiressettingupbeforeitcanbeused.
Important:
Y
ouwillneedtofillyourfueltankstocapacitybeforecalculationscanbemade.Thisislistedas
step6belowbutcouldalsobeperformedbeforestartingtheprocedure.
Fromthe Fuelmanagermenu:( Menu>Fuelmanager)
1.SelectFuelManager:
2.SelectEnternow.
3.Usethe Upbuttontoadjustthevaluetomatchthetotalfuelcapacityofyourfueltanks.
4.Select Save.
5.SelectOK.
6.Fillyourfueltankstocapacity.
7.Select Setalltanksfull
8.Select OK.
TheFuelmanagerwillnowperformfuelcalculations
.
8.4Settingtankfill
BeforeusingFuelmanageryoumustlogtheamountoffuelon-board.
Inthe
FuelManagermenu:
1.Forfirsttimeset-up:
i.Select Setalltanksfull.
2.Forallsubsequentfueling,either:
i.Select Addpartialfillandenterthevolumeoffuelyoufilledthetank(s)with.
ii.Select
Setalltanksfullifyoufilledthetank(s)tomaximumcapacity.
Important:Ifyouenterthewrongamountoffuelthiscanbecorrectedbyenteringaminusvalue
asapartialfuelfill,thiswillreducethetotalamountoffuelremainingbytheamountentered.
Thefuelmanagerisnowcalibratedandcapableofprovidingfuelusageestimates.
Note:
•Mak esuretologanyadditionalfuelingbyrepeatingeitherstepabove.
•Fuelremainingcalculationsareanestimateandwillbeinaccurateiffuelfillsarenotentered,
enteredincorrectly,oriffuelisusedbyothersources(e.g.:generators).
8.5Fuelcalculations
Fuelmanagercancalculateyourvessel’ sfuelestimatesusingtripdataorfuelflowratedata.
Tochoosefuelmanager’smethodforcalculating,fromthe FuelManagerscreen:
1.SelectSet-up.
2.SelectFuelcalculations.
3.Either:
i.Select FuelUsed(Trip).
ii.Select Fuelflowrate.
Fuelmanager
67
