Raymarine i70 - Wind Transducer Calibration

3.Usethe Upand DownbuttonstoselectthedesiredspeedthatyouwanttoaddaCalibration
pointfor.
4.Select Next.
5.Usethe Upand DownbuttonstoadjusttheCalibrationfactortothecorrectvalue.
6.Select Done.
7.Select AddtoaddthenextCalibrationpoint.
8.Repeatsteps3to7forallCalibrationpointsyouwanttoadd.
9.Select
FinishwhenallCalibrationpointshavebeenadded.
10.Select OK.
CalibratingWatertemperature
TheWatertemperaturereadingcanbecalibratedasfollows:
Y ouwillneedansuitablethermometertomeasurethetemperatureofthewater.
Fromafavoritepage:
1.Pressthe
Menubutton.
2.SelectSet-up.
3.Select
TransducersSet-up.
4.Select Continue.
Thedisplaywillsearchforandshowalistofconnecteddevices.(i.e.iTC-5,DSTortransducer
pod)
5.Selectthedevicethatthetransduceryouarecalibratingisconnectedto.
Alistofavailabletransducerdataisdisplayed.
6.
(1)
Select
Speed.
Important:
(1)S teponlyapplicabletoiTC-5.
7 .Select CurrentTemperatureoption.
8.Useasuitablethermometertomeasuretheactualwatertemperature.
9.Usethe Upand DownbuttonstomatchthedisplayedWatertemperaturetotheactualmeasured
watertemperature.
10.Select Savetosavethereading.
4.4Windcalibration
Calibratingwind
Calibrationofwindtransducersisimportanttoensureaccuratedataisdisplayed.
Prerequisites:
•Youwillneedtobeunderway,withsufficientspacetoturninalargeslowcircleunhindered.
34
