3.6T
ypicalsystems
Note:Thefollowingillustrationsshowthevariousproductsthatcanbeconnectedinatypical
system.Thesesystemsareshownasane
xampleonlyandmaydifferfromyourplanned
installation.Forinformationonavailablecablesandaccessories,refertotheChapter10Spares
andaccessoriessection.
Example:basicR
adarsystem(wireddataconnection)
ItemDescription
1
P owersupplyformultifunctiondisplay.
2Multifunctiondisplay .
3P owersupplyforRadome.
4
P owersupplyforSea Talkng®bus(MUSTbe12Vonly).
5
Quantum
™
2DopplerR adome.
6
Sea Talkng®bus(e.g.5-wayconectororbackbone).
7
EvolutionEV-1/EV-2(requiredforDopplerandMARP Afeatures).
Planningtheinstallation
