ttachasafetylanyard(notsupplied)toyourvessel,andsecurethefreeendtothescannerusing
theattachmentpointshowninthefollowingillustration:
ItemDescription
1
Safetylanyardattachmentpoint.
Note:IfyouareinstallingtheR adarscanneronasailingvessel,additionalprotectionfortheRadar
scannermayberequired.Referto5.3Radarscannerprotection—sailingvessels.
MultipleQuantumR adarscanners
Only1(one)Quantum
™
Radarscannercanbeusedatanyonetime,pernetworkedsystem.
IfyouhavemorethanoneQuantum
™
Radarscannerinstalledonyourvesselandwanttousethem
atthesametime,themultifunctiondisplaystowhichthescannersareconnectedmustNOTbe
networkedtogether.ThisappliestoQuantum
™
scannersconnectedeitherwiredorwirelessly.
Formoreinformation,referto:MultipleQuantumRadars—moreinformation.
MultipleRadarscanners—locationrequirements
Importantlocationconsiderationswheninstallingmultipleradarscannersonthesamevessel.
•Scannersshouldbemountedaboveeachother,verticallyseparatedbyatleast0.5m(1.6ft).This
appliestoallinstallationlocationsonthevessel.
•Multiplescannersshouldbemountedinawaythatminimizesinterferencebetweenthevertical
beamwidthsofthe2scanners.
•Inallcases,youshouldaimtoachieveasmuchphysicalseparationaspossible,tominimize
anypotentialinterference.
