.4RayNettoRayNetcablesandconnectors
DescriptionTypicaluseQuantity
1
S tandardRayNetconnection
cablewithaRayNet(female)
socketonbothends.
SuitableforconnectingallRayNetequipment
directlytoLightHousemultifunctiondisplays
featuringaRayNetconnector.Canalsobe
usedtoconnectRayNetequipmentviaa
RayNetnetworkswitch(e.g.HS5).
1
2
R ayNetcablepuller(5pack).
These“handles”securelyattachtothe
twist-lockonRayNetcables,enablingyouto
pullthecablesthroughconduitsandother
obstacles.
5
3
R ayNettoRayNet
right-anglecoupler/adapter.
SuitableforconnectingRayNetcablesat
90°(rightangle)todevices,forinstallations
wherespaceislimited.Forexample,use
thisadaptertoconnectaRayNetcabletoa
multifunctiondisplaywhenthereisnotenough
spacebehindthedisplayfortheusualcable
bendradiusrequiredbyastandardRayNet
cable.ThisadapterfeaturesaRayNet(female)
socketatoneend,andaRayNet(male)plug
attheotherend.
1
4AdaptercablewithaR ayNet
(male)plugonbothends.
Suitableforjoining(female)RayNetcables
togetherforlongercableruns.
1
Sparesandaccessories
93

Raymarine Quantum 2 Specifications

General

Transmit Power	20W
Beam Width	4.9° horizontal, 20° vertical
Weight	5.6 kg (12.3 lbs)
Power Supply	12-24 VDC
Power Consumption - Transmit	17W
Voltage Range	9-32 VDC
Waterproof Rating	IPX6
Rotation Speed	24 rpm
Radar Type	CHIRP Pulse Compression
Range	24 nautical miles
Connectivity	Wi-Fi
Storage Temperature Range	-25°C to +70°C (-13°F to +158°F)
Humidity	Up to 95% relative
Compatibility	Raymarine Axiom
Radar Range Scales	1/16, 1/8, 1/4, 1/2, 3/4, 1.5, 3, 6, 12, 24
Operating Temperature Range	-15°C to +55°C (5°F to 131°F)
Frequency	X-Band (9.375 GHz)
