Chapter 4: Setup and Calibration 29
Menu Options Factory New
Default Default
Depth Units FEET FEET
METRES
FATHOMS
Depth Offset Value 0
Sounder Control ON ON
OFF
Audible Alarm ON ON
OFF
Speed Units KMH KNOTS
MPH
KNOTS
Temperature Units DEG C DEG F
DEG F
Distance Units KM NM
SM
NM
Position LAT LON LAT LON
TD (only with NMEA input )
Variation Variation value: 0
plus [W] or minus [E] up to
30°, in whole degrees
True/Magnetic Mode TRUE MAGNETIC
MAGNETIC
Depth Response Level 1 - 15 4
Speed Response Level 1 - 15 4
Temperature Response Level 1 - 15 4
Heading Response Level 1 - 15 4
Time Format 12 HOUR 24 HOUR
24 HOUR
Time Offset Offset value: 0
Plus or minus up to 12 hours,
in whole hours
