Appendix C: Specification
This appendix provides the physical and electrical specification for the
RayData.
Size 4.5” x 4.3” x 1.8” (11.2 x 11.0 x 4.5 cm)
Weight 12.3 oz (0.35 Kg)
Waterproofing To CFR46; suitable for external mounting
Mounting Panel with trunnion options
Power External 10 -16 volts DC required
Controls 5 keys: NAV, DEPTH, SPEED, Ú and Ù .
Display types STN, 101 x 64 resolution
Display size 3.35” x 2.06” (8.25 x 5.3 cm)
Interfaces SeaTalk , receive and transmit
NMEA 0183, receive
