Chapter 6: The Display Pages 43
Chapter 6: The Display Pages
6.1 Introduction
The RayData can display a wide range of information in the form of
pages, which are grouped into chapters. Each of the main chapters -
Depth, Speed and Nav - is accessed directly using a dedicated key.
When you press the NAV, SPEED or DEPTH key to access the
required chapter, the page displayed is the main page that was used
last from that chapter.
This chapter of the handbook provides reference information on the
following:
• The Depth Chapter, which includes depth, temperature and three-
line pages
• The Speed Chapter, which includes speed, log and three-line pages
• The Nav Chapter, which includes navigation pages, if the RayData is
connected to other instruments that make this information available
For each chapter, the individual pages (and their sub-pages) are
described in detail, excluding the the alarm setup pages which are
described in Chapter 5. The pages in the Setup Chapter are described
in Chapter 4.
For instructions on operating the RayData, and general information on
the displays, refer to Chapter 3, “Getting Started”, and to the RayData
Quick Reference Card included with your RayData.
Note: Each page description includes information on the effect of key
presses that are specific to that page. The following key press
combinations have the same effect, irrespective of the page displayed
when they are pressed:
Keys Page Displayed
ÚÚ
ÚÚ
Ú
+
ÙÙ
ÙÙ
Ù
Locked Heading page, unless the current page
indicates that this key combination is used for a
different purpose (see Section 3.7)
SPEED+DEPTH MOB page (see Section 3.8)
NAV+
ÙÙ
ÙÙ
Ù
First Setup Chapter page (see Chapter 4)
Refer to the Key Functions table in Appendix A for further information.
