Appendix A: Key Functions 67
Appendix A: Key Functions
The function of each of the five RayData keys depends on:
• The circumstances in which it is pressed: that is, the information that
is currently displayed on the screen
• The way in which it is pressed: that is, whether you press the key
momentarily or press and hold it
• Whether it is pressed in combination with other keys
The following table reviews the functions of all the RayData key
presses, including combination key presses, depending on how they
are pressed and in what circumstances.
Key Press/ Condition / display Function
Hold
NAV P System is off Turns RayData on
H System is on Turns RayData off after 3 seconds
P System is on and navigational Nav Chapter main page (last used) displayed
data available via SeaTalk or
NMEA; non-Nav Chapter page
P System is on and navigational Moves on to next main page in the Nav
data available via SeaTalk or Chapter
NMEA; Nav Chapter page
P Speed calibration Exits and saves calibration value
NAV+
ÙÙ
ÙÙ
Ù
P Normal display First Setup page displayed
P Setup page Exits Setup and validates changes
NAV+
ÚÚ
ÚÚ
Ú
P Setup page Enters self test mode
P Self test mode Returns to Setup page
DEPTH P Non-Depth Chapter page Depth Chapter main page (last used)
displayed
P Depth Chapter page Moves on to next main page in the Depth
Chapter
H Normal display Lighting Control page displayed
P Lighting Control page Moves on to next Lighting Control option
P Speed Calibration mode Changes calibration run number
Continued overleaf
