Raymarine RVX1000 User Manual

W
arning:Sonaroperation
•NEVERoperatethesonarwiththevesseloutofthewater
.
•NEVERtouchthetransducerfacewhenthesonarispoweredon.
•SWITCHOFFthesonarifdiversarelikelytobewithin7.6m(25ft)ofthe
transducer.
Caution:Donotcuttransducercables
•Cuttingthetransducercableseverelyreducessonarperformance
.Ifthecable
iscut,itmustbereplaced,itcannotberepaired.
•CuttingthetransducercablewillvoidthewarrantyandinvalidatetheEuropean
CEmark.
Caution:Serviceandmaintenance
Thisproductcontainsnouserserviceablecomponents.Pleasereferall
maintenanceandrepairtoauthorizedRaymarinedealers.Unauthorizedrepair
mayaffectyourwarranty.
W ateringress
Wateringressdisclaimer
AlthoughthewaterproofratingcapacityofthisproductmeetsthestatedIPXstandard(refertothe
product’s
TechnicalSpecification ),waterintrusionandsubsequentequipmentfailuremayoccurif
theproductissubjectedtocommercialhigh-pressurewashing.Raymarinewillnotwarrantproducts
subjectedtohigh-pressurewashing.
Disclaimer
Raymarinedoesnotwarrantthatthisproductiserror-freeorthatitiscompatiblewithproducts
manufacturedbyanypersonorentityotherthanRaymarine.
Raymarineisnotresponsiblefordamagesorinjuriescausedbyyouruseorinabilitytousethe
product,bytheinteractionoftheproductwithproductsmanufacturedbyothers,orbyerrorsin
informationutilizedbytheproductsuppliedbythirdparties.
EMCinstallationguidelines
RaymarineequipmentandaccessoriesconformtotheappropriateElectromagneticCompatibility
(EMC)regulations,tominimizeelectromagneticinterferencebetweenequipmentandminimizethe
effectsuchinterferencecouldhaveontheperformanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformanceisnotcompromised.
Note:Inareasofe xtremeEMCinterference,someslightinterferencemaybenoticedonthe
product.Wherethisoccurstheproductandthesourceoftheinterferenceshouldbeseparated
byagreaterdistance.
ForoptimumEMCperformancewerecommendthatwhereverpossible:
•R aymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingorcablescarryingradiosignalse.g.VHFradios,
cablesandantennas.InthecaseofSSBradios,thedistanceshouldbeincreasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.Aradarbeamcannormallybeassumedto
spread20degreesaboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatusedforenginestart.Thisisimportant
topreventerraticbehavioranddatalosswhichcanoccuriftheenginestartdoesnothavea
separatebattery.
