CHIRPtransducers
ThetransducerslistedbelowcanbeconnecteddirectlytotheR
VX1000RealVision™3DCHIRP
sonarmodule.
Note:T
oinstallindividualB75orB175transducers,usetheSingleB75/B175OperationCable
(A80328)insteadofthePairedCHIRPTransducerY-cable(A102146).
ProductnumberT
ransducerMountingDescription
A
80013
T
ransom
TM265LHplastic
A 80041
Transom
TM265LMplastic
A 80012
In-Hull
M265LHplastic
A 80038
In-Hull
M265LMplastic
A 80016
Thru-Hull
B75L0°angled
elementbronze
A 80017
Thru-Hull
B75M0°angled
elementbronze
Planningtheinstallation
37
