Raymarine RVX1000 User Manual

SimultaneousR
ealVision™andtraditionaltransducerconnections
ItemDescription
1
R VX1000
2
Extensioncable(optional)
3
R ealVision™transducer
4
11-pinto8-pinadaptorcable(A 80496)
5T raditionaltransducer
T ransducercableextension
Forsomeinstallationsitmaybenecessarytoextendthetransducercable.
•RefertoChapter10Sparesandaccessoriesforalistofsuitabletransducerextensioncables.
•Raymarinerecommendsamaximumofonecableextensionforanysingletransducercable.
•Forbestperformance,keepallcablelengthstoaminimum.
CableextensionsforWideBeamtransducers
AllWideBeamtransducersaresuppliedwithafixed2mcable.
Y oumustpairthefixed2mcablewithanappropriateextensioncabletoconnecttheWideBeam
transducertoyourCHIRPsonarmodule.
ForpairedWideBeamtransducerinstallations,extensioncablesmustbeplacedbetweenthe
Y-cableandthetransducer.
