24 SmartPilot X-Series Commissioning & Setup Guide
The default data page settings are:
Setting up data pages
When setting up your data pages, we recommend that you:
• Retain the
BTW and DTW data pages. If your SPX system receives a man
overboard (MOB) message, these data pages will show the bearing and distance
to the MOB location.
• Disable data pages you do not need to
NOT USED . These will then not be
displayed during normal operation, thereby improving the access time to the other
data pages.
.
Data Page Default Setting
1
XTE (Cross Track Error)
2
BTW (Bearing to Waypoint) - see Note below
3
DTW (Distance to Waypoint) - see Note below
4
RESPONSE
Remaining pages
NOT USED (see Setting up data pages below)
Available Data Pages Displayed as
Speed Knots
SPEED KTS
Log LOG XXXX .X
Trip
TRIP XXX.X
Average Speed AV. SPD
Wind Direction e.g. WIND PORT
Wind Speed WIND KTS
Depth Metres DEPTH M - see Note below
Depth Feet
DEPTH FT - see Note below
Depth Fathoms
DEPTH FA - see Note below
Heading
HEADING
Water Temperature, Degrees C WATER °C - see Note below
Water Temperature, Degrees F
WATER °F - see Note below
Course Over Ground
COG
Speed Over Ground, Knots SOG KTS
Cross Track Error XTE
Distance to Waypoint DTW
