Raymarine SmartPilot X-Series User Manual

37
SmartPilot X-Series Specifications
Nominal supply voltage
X-10
X-30
X-SOLENOID
X-CAN
12 or 24 V DC (fuse protected at 15A)
12 or 24 V DC (fuse protected at 40A)
12 or 24 V DC (fuse protected at 15A)
12 or 24 V DC (fuse protected at 10A)
Operating voltage range 10 V to 32 V DC
Power consumption (standby)
(all types)
300 mA
Gyro internal GyroPlus fitted onto circuit board as standard
Environmental conditions
operating temperature
non-operating temperature
relative humidity limit
water protection
-10°C to 55°C (14°F to 131°F)
-20°C to 70°C (-4°F to 158°F)
80%
drip resistant when mounted vertically
Storage conditions when
packed
temperature range
relative humidity limit
-5°C to 50°C (23°F to 122°F)
75%
Dimensions (width, height, depth)
307mm (12.1 in), 195 mm (7.7 in), 70 mm (2.8 in)
Weight
(all types)
2.2 kg (4.85 lbs)
Inputs
All types
X-10, X 30 & X-SOLENOID
only
Fluxgate compass, NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, power,
sleep switch.
Rudder position sensor,
Outputs
X-10, X -30
X-SOLENOID
X-CAN
NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, drive motor, drive clutch
NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, bypass valve, solenoid drive
NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, CAN (IPS)
Steering drive compatibility
X 10
X 30
X-SOLENOID
X-CAN
All Type 1 drives/pumps (excluding CR pumps) (drive voltage must
match boat’s supply voltage)
All Type 1, Type 2 and Type 3 drives / pumps (drive voltage must
match boat’s supply voltage)
CR pumps etc.
Volvo Penta IPS system.
Drive motor output
X-10
X-30
continuous 10A at supply voltage
continuous 30A at supply voltage
81307_1.book Page 37 Wednesday, December 19, 2007 11:17 AM
