Reboot RBC5000D - Technical Specificationsrbc 5000 D

CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
A-4 INSTALLATION
A-4
TECHNICAL SPECIFICATIONS -RBC5000D
INPUT-SINGLEPHASE 60HERTZ
Standard Voltage
110V/220V ±10% / 1 / 60Hz
RATED OUTPUT AT 25°C
Input Voltages
Duty Cycle
CURRENT AMPS
VOLTAGE VOLTS
110Vac ± 10%
100%
25.5 A
90.2 VDC
60%
33.0A
93.2VDC
220Vac ± 10%
100%
33.3A
93.3VDC
60%
43.0A
97.2VDC
OUTPUT
Input Voltages
Current Range
Open Circuit Voltage
Pilot Current
110Vac ± 10%
15-35Amps
260 VDC
NO
220Vac ± 10%
15-45Amps
260 VDC
NO
REQUIRED GAS FLOW RATE
REQUIRED GAS INLET PRESSURE
70 PSI @ 125-200 SCFH
( 5 Bar. @ 80±20 LITERS/MIN.)
80 to 110 PSI
(6 Bar. to 7.5 Bar.)
RECOMMEND INPUT WIRE AND FUSE SIZES
For all plasma cutting applications
Based on Ambient Temperature ≤30
o
C
Output
AC Input
Voltage
at
60 Hertz
Input Cord Plug Size
Fuse (Super
Lag)
Circuit Breaker
(Delay Type)
Type S, SO, ST, STO or extra
hard usage input cord
AWG (IEC) Sizes
2 Input Supply Wires
1 Ground Wire
35Amps
110V-1Ø
5-15P
50 AMPS
#10 (4.0 mm
2
)
#10 (4.0 mm
2
)
45Amps
220V-1Ø
6-50P
50 AMPS
#10 (4.0 mm
2
)
#10 (4.0 mm
2
)
PHYSICAL DIMENSIONS
Height
19.3 in.
490 mm
Width
11.5 in.
290 mm
Depth
13.4in.
34 0mm
Weight
Including
Torch Cable
22.16 lbs.
10.05 kg.
TEMPERATURE RANGES
OPERATING TEMPERATURE RANGE
-10°C to +40°C
STORAGE TEMPERATURE RANGE
-10°C to +40°C
