A-1 INSTALLATION A-1
CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
A-3 INSTALLATION A-3
TECHNICAL SPECIFICATIONS -RBC5000
INPUT-SINGLEPHASE 60HERTZ
Standard Voltage
220V ±10% / 1 / 60Hz
RATED OUTPUT AT 25 °C
Duty Cycle
CURRENT AMPS
VOLTAGE VOLTS
100%
33.3 A
93.3 VDC
60%
43 A
97.2 VDC
OUTPUT
Current
Range
10-45 Amps
Open Circuit
Voltage
260 VDC
Pilot Current
NO
REQUIRED GAS FLOW RATE
REQUIRED GAS INLET PRESSURE
70 PSI @ 125-200 SCFH
( 5 Bar. @ 80±20 LITERS/MIN.)
80 to 110 PSI
(6 Bar. to 7.5 Bar.)
RECOMMEND INPUT WIRE AND FUSE SIZES
For all plasma cutting applications
Based on Ambient Temperature ≤30
o
C
Output
AC Input
Voltage
at
60 Hertz
Input Cord Plug Size
Fuse
(Super Lag)
Circuit Breaker
(Delay Type)
Type S, SO, ST, STO or extra
hard usage input cord
AWG (IEC) Sizes
2 Input Supply Wires
1 Ground Wire
45 A
220V-1Ø
6-50P
50 AMPS
#10 (4.0 mm
2
)
#10 (4.0 mm
2
)
PHYSICAL DIMENSIONS
Height
19.3 in.
490 mm
Width
11.5 in.
290 mm
Depth
13.4 in.
34 0 mm
Weight
Including
Torch Cable
22.16 lbs.
10.05 kg.
TEMPERATURE RANGES
OPERATING TEMPERATURE RANGE
-10°C to +40°C
STORAGE TEMPERATURE RANGE
-10°C to +40°C
