Reboot RBC5000D - Accessories

CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
C-1
ACCESSORIES C-1
ACCESSORIES / OPTIONS
Standard Accessories
1.Earth clamp
With earth lead and euro plug Length for earth lead is anoption
2.Air regulator
Air regulator must be installation before use machine, Set the air pressure
rang: 70 PSI to 80 PSI, User can adjust it accordingly to getbetter cutting,
Machine maybe can not cut in higher or lower airpressure.
3.Plasma cutting torch AS-31
Depend on model, standard torch AS31 or pilot-arc Torch AS60P would be
supplied with machine. User also can select other model of torch. Accessories:
① Ceramic cup
② Tip / Nozzle
③ Electrode
④ Ceramic ring / diffuser
4.Pilot-arc AS60P
60Amps pilot cutting torch Wires support in torch head
Tokeep a distance from torch head to the metal, extend parts life’s
longer.
5.Pilot-arc AS65P – different handle
60Amps pilot cutting torch Wires support in torch head
Tokeep a distance from torch head to the metal, extend parts life’s
longer.
6.Accessories for AS60 &AS60P
Torch accessories are consumable, need to buy in Separately.
① Torch head
② Electrode
③ Tip / Nozzle
④ Ceramic cup
