Reboot RBC5000D - Installation; Technical Specificationsc Ut 40 (110 V

CAUTION
If for any reason you do not understand the test procedures or are unable to perform the tests/repairs safely, contact your
Local Authorized Field Service Facility for technical troubleshooting assistance before you proceed.
A-1 INSTALLATION
A-1
TECHNICAL SPECIFICATIONS -CUT40（110V）
INPUT-SINGLEPHASE 60HERTZ
Standard Voltage
110V ±10% / 1 / 60Hz
RATED OUTPUT AT 25 °C
Duty Cycle
CURRENT AMPS
VOLTAGE VOLTS
100%
23 A
89 VDC
60%
30 A
92 VDC
OUTPUT
Current Range
Open Circuit Voltage
Pilot Current
15-30 Amps
240 VDC
NO
REQUIRED GAS FLOW RATE
REQUIRED GAS INLET PRESSURE
70 PSI @ 125-200 SCFH
( 5 Bar. @ 80±20 LITERS/MIN.)
80 to 110 PSI
(6 Bar. to 7.5 Bar.)
RECOMMEND INPUT WIRE AND FUSE SIZES
For all plasma cutting applications
Based on Ambient Temperature ≤30
o
C
Output
AC Input
Voltage
at
50\60
Hertz
Input Cord Plug Size
Fuse
(Super Lag)
Circuit Breaker
(Delay Type)
Type S, SO, ST, STO or extra
hard usage input cord
AWG (IEC) Sizes
2 Input Supply Wires
1 Ground Wire
30 A
110V-1Ø
5-15P
50 AMPS
#12 (3.3 mm
2
)
#12 (3.3 mm
2
)
PHYSICAL DIMENSIONS
Height
16.9 in.
430 mm
Width
11 in.
280 mm
Depth
12.6 in.
320 mm
Weight
Including
Torch Cable
17.42 lbs.
7.9 kg.
TEMPERATURE RANGES
OPERATING TEMPERATURE RANGE
-10°C to +40°C
STORAGE TEMPERATURE RANGE
-10°C to +40°C
