Record 5100 Series - Driving Cycle - Speed and Force; Speed and Movement Control; Force and Ramp Settings

Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
Open
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
DRIVING CYCLE
Closing speed 20
Opening speed 36
Open >
CLOSING SPEED
24
The closing speed
is limited to 1 foot
per second max.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
OPENING SPEED
36
Close >
Ramp >
Seal >
DRIVING CYCLE
Open >
Close >
Ramp >
Seal >
Closing speed 20
Opening speed 36
DRIVING CYCLE
Close >
Ramp >
Seal >
Closing speed 20
Opening speed 36
Open >
Acceleration 30
Deceleration 35
Creep Section 1
Acceleration and
Deceleration: Higher
value= faster cycle
0= no creep section
1= 2.5% of last travel
40= 100% of travel
Note: As Creep
Section is increased,
door speed is
decreased.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
Close
DRIVING CYCLE
Ramp >
Seal >
Closing speed 20
Opening speed 36
Open >
Acceleration 30
Deceleration 30
Creep Section 1
Close >
Holding Force 5
0= no creep section
1= 2.5% of last travel
40= 100% of travel
High Holding Force
increases Motor Temp.
Recommend not to
exceed a setting of 20.
Push to Actuate
cancels Holding Force.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
Ramp
DRIVING CYCLE
Seal >
Closing speed 20
Opening speed 36
Open >
Section 1
Close >
Force 1
Ramp >
DRIVING CYCLE
DRIVING CYCLE
DRIVING CYCLE
Section= Length of
Ramp. 0= no ramp
1= appr. 1.5” ramp
40= appr. 4.75” ramp
measured @ belt.
Force & ramp should
be kept to minimum
for no obstruction
during force & ramp.
During Ramp, Obstruction sensitivity is significantly reduced
