Record 5100 Series - Display Brightness and Operation Modes; Brightness Adjustments; Default Operational Mode

Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
When set to “0”, the
backlight is always off;
1-39 = seconds “on” time;
40 = backlight always “on”.
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control panel >
Locking >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control panel >
Locking >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control panel >
Locking >
CONTROL PANEL
Mechanical Panel 3
Display panel >
Default op. mode
DISPLAY PANEL
Language 3
Keyboard 1
Contrast BDE1 20
Contrast BDE2 20
Brightness BDE1 20
Brightness BDE2 20
BRIGHTNESS BDE1
20
CONTROL PANEL
Mechanical Panel 3
Display panel >
Default op. mode
DISPLAY PANEL
Language 3
Keyboard 1
Contrast BDE1 20
Contrast BDE2 20
Brightness BDE1 20
Brightness BDE2 20
BRIGHTNESS BDE2
20
CONTROL PANEL
Mechanical Panel 3
Display panel >
Default op. mode
DISPLAY PANEL
Keyboard 1
Contrast BDE1 20
Contrast BDE2 20
Brightness BDE1 20
Brightness BDE2 20
TD Backlite 10
10
TD BACKLITE
CONTROL PANEL
Mechanical Panel 3
Display panel >
Default op. mode 0
Default op. mode
0 Off
1 Locked
2 Automatic
3 Cont. Open
4 One-way
Determines the operating mode when there is no Display module connected or a
Mechanical Panel configured.
