Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control Panel >
Locking >
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
DOOR LEAF
1 EST - L/R
0 DST
Supports calculation of door
parameters.
DST=Bi-parting Door D-STA,D-TSA
EST-L/R=Single Slide Door
Left/Right, E-STA, E-TSA
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control Panel >
Locking >
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
INTERLOCK
1 All Operation Modes
2 Only One-Way Locked
Requires a FEM-1.
Direction detecting sensors are
recommended to avoid nuisance open
cycles (depending on the operating
mode).
A SIS-signal during the closing cycle
affects only the open door.
The reduced opening width is
supported. Refer to 5100 Installation
Instructions for more detail..
0 Disabled
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control Panel >
Locking >
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 19
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
ENTRANCE SYSTEM
Door type 20
Measure A 0
Measure G 0
Door Leaf 0
Interlock 0
DOOR TYPE
12 Flip Flow
14 Co48 Sandoe Direct
15 Basic Escape Route
18 Folding Door Austria
19 Folding Door USA
20 Breakout USA
NOTICE: A modification of door type
causes a reset of the running
parameters and sets certain
parameters, such as AUX0-IN, to a
predefined function.
Typically select “Break-out USA”; select “Ratchet” for Push-to-Open/Push-to-Close operation.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control Panel >
Locking >
CONTROL PANEL
Mechanical Panel 3
Display panel >
Default op. mode
MECHANICAL PANEL
3 disabled
4 Standard one-way
5 Rkr &/or keysw
7 Standard Reduced
0 3 Pos. (Auto)
Typically select “disabled” unless one of the Rocker switch control panels has been connected.
MECHANICAL PANEL
3 disabled
4 Standard one-way
5 Rkr &/or keysw
7 Standard Reduced
0 3 Pos. (Auto)
Enables more accurate automatic
setting of door cycle parameters,
providing a smoother, more efficient
door operation.
For proper door operation, Inputs AUX00_IN and AUX01_IN (parameter Input/Output / STG) must
be properly enabled, and panel connected per diagram S5100Sys20MechanicalControlPanels.
