Record 5100 Series - Miscellaneous System Functions; SIA and TOWA Functionality; Push-to-Actuate and Holding Force

If the door is in “Partial Open” mode,
enabling TOWA will provide full door
opening if traffic approaches on both
sides, or occurs for more than 10 sec.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
CAN-BUS >
Input/Output >
Miscellaneous >
Entrance System >
Control Panel >
Locking >
INPUT/OUTPUT
Ext. Sw IN 0
Emerg. Open/Close 0
EMERG, STOP Reset 0
SIO >
SIS 2
SIA 1
SIA
1 Stop
2 Creep
SIA=Function of
door with safety
signal across
door opening
while closed,
typically folding
door.
SIO=Function of
door with safety
input during
opening cycle.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
CAN-BUS >
Input/Output >
Miscellaneous >
Entrance System >
Control Panel >
Locking >
MISCELLANEOUS
TOWA 1
Push to actuate open 0
Push to actuate close 0
Holding force 0
Lead time open 0
Lead time close 0
TOWA
0 disabled
1 enabled
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
CAN-BUS >
Input/Output >
Miscellaneous >
Entrance System >
Control Panel >
Locking >
MISCELLANEOUS
TOWA 1
Push to actuate open 0
Push to actuate close 0
Holding force 0
Lead time open 0
Lead time close 0
Push to actuate open
0 Disabled
0 Normal
0 Partial
Default: Disabled
Normal: If enabled, will automatically
open after pushed 3mm from closed
position
Partial: Opens to reduced width.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
CAN-BUS >
Input/Output >
Miscellaneous >
Entrance System >
Control Panel >
Locking >
MISCELLANEOUS
TOWA 1
Push to actuate open 0
Push to actuate close 0
Holding force 0
Lead time open 0
Lead time close 0
Push to actuate close
0 Disabled
0 Normal
Default: Disabled
Normal: If enabled, will automatically
close after pushed 30mm from closed
position
Holding force can be used.
Hold open time has no influence.
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
PARAMETER
CAN-BUS >
Input/Output >
Miscellaneous >
Entrance System >
Control Panel >
Locking >
MISCELLANEOUS
TOWA 1
Push to actuate open 0
Push to actuate close 0
Holding force 0
Lead time open 0
Lead time close 0
Holding force
0
Force required to
activate “Push
to actuate”
function in
opening and
close.
