Record 5100 Series - Driving Cycle - Opening and Motor; Opening Limits and Obstruction Sensitivity; Motor Type and Dual Motor Configuration

Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Operation mode >
SERVICE STG
Maintenance >
Functions >
Configure System
Learning System >
Parameter >
Reduced opening limits:
0 = 8 inches (minimum);
40 = 100% of opening.
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
DRIVE
Partial opening 20
Obstruction close 25
Obstruction open 25
Brake 0
PARTIAL OPENING
20
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
If the door is reversing due to
extraordinarily tight weather seals
or extreme stack pressures,
change from 0 to higher number.
Motor
Two Mot
DRIVE
Partial opening 20
Obstruction close 25
Obstruction open 25
Brake 0
Motor 6
Two Motors 0
Obstruction close
25
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
DRIVE
Partial opening 20
Obstruction close 25
Obstruction open 25
Brake 0
Motor 6
Two Motors 0
Obstruction open
25
If the door is reversing due to
extraordinarily tight weather seals
or extreme stack pressures,
change from 0 to higher number.
DRIVE
Partial opening 20
Obstruction close 25
Obstruction open 25
Brake 0
Motor 3
Two Motors 0
PARAMETER
Driving Cycle >
Time delay open >
Drive >
Entrance System >
Control unit >
Locking >
Motor
0 Without
3 ATE20
4 ATE21
5 ATE19 small
6 ATE19 large
7 ATE16 normal
Automatic Identification with current
System 20 Motor
Definition of the Motor type being used.
DRIVE
Partial opening 20
Obstruction close 25
Obstruction open 25
Brake 0
Motor 6
Two Motors 0
Two Motors
0 Disabled
1 Enabled
Normally, the second motor is
automatically identified.
Note: Brake not available in North
America
If older unit (System 19) with small
encoder, select “ 6 ATE19 Large
