Record 5100 Series - Function Testing and System Calibration; Release AKI and ELS Testing; Learning Parameter and System Reset

Used to test an optional battery backup.
Operation mode >
SERVICE STG
Diagnostics >
Learning System >
Parameter >
Maintenance >
Functions >
FUNCTIONS
Factory settings >
Release AKI >
Learning ELS >
Learning parameter >
BAT emerg. reaction >
Default Settings >
Selecting “Release AKI” and pressing “OK” will
simulate an actuation from the Interior Sensor.
Initiates an aquisition of safety beam
characteristics.
Operation mode >
SERVICE STG
Diagnostics >
Learning System >
Parameter >
Maintenance >
Functions >
FUNCTIONS
Factory settings >
Release AKI >
Learning ELS >
Learning parameter >
BAT emerg. reaction >
Reset system
Operation mode >
SERVICE STG
Diagnostics >
Learning System >
Parameter >
Maintenance >
Functions >
FUNCTIONS
Factory settings >
Release AKI >
Learning ELS >
BAT emerg. reaction >
Reset system
Learning parameter >
For use when initially commissioning a
door, or significantly altering the
mechanical characteristics of the door.
Learning parameter
Are you sure?
Yes No
Parameter >
Maintenance >
Functions >
Operation mode >
Diagnostics >
Operation mode >
SERVICE STG
Diagnostics >
Learning System >
Parameter >
Maintenance >
Functions >
Cycles 123
Door parameters >
Peripheral devices >
Software >
FUNCTIONS
Factory settings >
Release AKI >
Learning ELS >
Learning parameter >
Reset system >
BAT emerg. reaction >
BAT emerg. reaction
Are you sure?
Yes No
Operation mode >
SERVICE STG
Diagnostics >
Learning System >
Parameter >
Maintenance >
Functions >
Cycles 123
Door parameters >
Peripheral devices >
Software >
FUNCTIONS
Factory settings >
Release AKI >
Learning ELS >
Learning parameter >
BAT emerg. reaction >
Reset system >
Reset system
Are you sure?
Yes No
Minor reset to clear faults without requiring a
calibration cycle.
