Page 16 of 55 12/2006 Rev. B Manual DFA 127 Full Power
11 Installation and commissioning
• Assembly of the ATM operator module
• Fix the NET mains supply and connect the connector cables to the STG con-
troller.
• Prepare the arms (refer to: 10 Adjustment of the arms), fix the arms in correct
position with regard to the DFA, screw the arms to the door leafs and adjust
the angle (90°) of the arms to the door leaf
