Record DFA 127 - Special Remarks

Manual DFA 127 Full Power 12/2006 Rev. B Page 37 of 55
Parametrierung
UK
Parameter Factory
default
Parameter Factory
default
MANUAL CONTROL
When locked Enabled
When automatic Enabled
UK Low Energy
Parameter Factory
default
Parameter Factory
default
DRIVING CYCLE MANUAL CONTROL
Closing speed 10 During closing Enabled
Opening speed 20 When locked
Enabled
Acceleration 15 When automatic
Enabled
DRIVE Collision
Enabled
Collision 5 Closing speed 10
15.3 Special remarks
1)
If the value 2 has been programmed and an external mechanical BDE (BDE-M)
has been connected, the inputs (BDE1, BDE2) will be interpreted in a different
manner. On the circuit board in the mounting set, BDI-M DFA 127 (127.808.232)
is equipped with clamps that permit the external adjustment of the operation mode
according to the table below.
Terminal connections on the circuit board in the mounting set:
Input/output on
STG DFA 127
Clamps on STG
DFA 127
Clamp marking on
BDI-M
BDE 1 J7/1 1
BDE 2 J7/2 2
+ 24 V J7/3 3
If using the circuit board on the side cover, only the RESET button and the
Status signal remain in function!
