Control references with new assembly
The following points must be checked:
Base fixing
Is the DFA 127 securely fixed to the backing construction?
Chassis
Is the attachment still normal?
Door hinge
Can the door leaf be moved smoothly?
Door leaf
Do the leaf weight and the leaf width correspond to the defaults
in accordance with diagram in this manual?
Arm
Has the fixing screw of the arm been firmly tightened?
Function
Does the movement of the door give reason for dissatisfaction?
Electric supply
Is the outer sheathing of the supply cable intact up to the mains
adaptor cover?
Wiring
Are all cables connected and have the clamping screws been
firmly tightened? Are all the connection assemblies to the motor
in order?
Control unit con-
nection
Was the prescribed cable used and has it been installed cor-
rectly?
Configuration
Was the operator configured in accordance to the default?
Was the configuration sheet filled out and placed under the op-
erator’s casing?
Calibration run
Has a calibration run been completed?
Control unit
Functional check of all operation modes
Actuating devices
Adjustment and functional test of motion sensors, push button,
pull-switch, etc.
Safety elements
Adjustment and functional test of safety cells on door leaves
(SIO/SIS)
Safety functions
Check external connections (fire alarm, EMERGENCY STOP,
SSK)
