Commissioning
Legend:
M
Master-operator
S
Slave-operator
MF
Multifunctional switch on controller
FPC
record programming device (Flash-Programmer)
Operator Instructions Description
M+S
Operators are turned off
M+S
Adjust initial spring tension Procedure according to chapter
11.4 and table in chapter 3.1
M+S
Check that the switch for direction
of rotation is adjusted correctly
Setting according to chapter 11.5
The arms must not be connected
to the operator
M+S
Check that the CAN-connection
has been made over the CAN-
insulation
M Check that Jumper 13 is set to M1
on STG
HW detection for Master STG
S Check that Jumper 13 is set to S1
on STG
HW detection for Slave STG
M
Switch operator to manual mode With operation switch BDI
M+S
Turn on operators
M+S MF 8. light pulse
Load default parameters
M MF 6. light pulse
FPC 902: Master / Diagnostic /
Door parameters
Separate the arm from the opera-
tor!
Carry out the spring learning.
Check the spring value and read-
just if necessary.
M
FPC 902: Master / Parameter /
Drive / Arms
Check the correct settings of type
of arms
S MF 6. light pulse
FPC 902: Slave / Diagnostic / Door
parameters
Separate the arm from the opera-
tor!
Carry out the spring teaching.
Check the spring value and read-
just if necessary.
S
FPC 902: Slave / Parameter / Drive
/ Arms
Check the correct settings for the
type of arm
