Manual DFA 127 Full Power 12/2006 Rev. B Page 39 of 55
Configurations
For Master/Slave operators, the input AKA can be configured so that only
the Master door leaf (moving leaf) opens if there is a trigger!
Menu: MS 2-Leaves / Function AKA / Master only
Connection of a time switch for "locked" (SUR-V)
* Contact closed = mode of operation according to the position of
the operation switch
Contact open = “Locked” mode of operation
In combination with a BDE-D control unit, it is recommended to acti-
vate the control lock of the BDE-D ( or ).
Otherwise, the door can no longer be unlocked using an external me-
chanical BDE-M or external signals to the BDI-M circuit board after selec-
tion of the "Locked" operating mode if it has been locked in the meantime
with the BDE-D!
