Introduction Kits And Accessories
8
1. Select UMP (HP and voltage requirements).
2. Select piping kit
If piping version with No Pressure Relief is chosen, the customer must select the Adjustable
Pressure Relief kit (see Item 5 below).
3. For multiple dispenser applications select the Isotrol box:
• Isolates the handle signals between each dispenser
• Isolates and protects individual dispensers from wiring shorts or phasing issues
• Isolates and protects technicians from dangerous feedback during service
• Accepts up to eight individual dispenser signals
Part Number
Model
Number HP Volts Hz Phase
Length
(‘B’ Figure 3) Weight
410852-001 DP75U1 3/4 230 60 1 16.81” (427mm) 22 lbs. (10kg)
410852-002 DP75U3 3/4 230 50 1 16.81” (427mm) 22 lbs. (10kg)
410852-003 DP200U1 2 230 60 1 23.94” (608mm) 34.2 lbs. (15.5kg)
410852-004 DP200U17 2 400 50 3 23.94” (608mm) 34.2 lbs. (15.5kg)
410852-005 DP200U4 2 230 60 3 23.94” (608mm) 34.2 lbs. (15.5kg)
Part Number Description
410869-001 D1 with 1/2” Pressure Relief - 3/4 HP
410869-002 D2 with 1/2” Pressure Relief - 3/4 HP
410869-003 D1 with 1-1/4” Pressure Relief- 2 HP
410869-004 D2 with 1-1/4” Pressure Relief - 2 HP
410869-005 D1 with no Pressure Relief - 3/4 or 2 HP
410869-006 D2 with no Pressure Relief - 3/4 or 2 HP
Isotrol Box Hook Voltage P/N
W/O Relay For
Standalone
120V hook 880-049-1
240V hook 880-050-1
W/Relay For Mani-
folded
120V hook 880-047-1
240V hook 880-048-1
